Machine Tools & Accessories

Mars-Tech BT40ER25UM- Collet Chuck 70... from ₹ 1,505.00

BT40 Tool Holder accepts all ER25 collets ER25 Collets range from 1 mm to 16 mm Thread inside internal stop screwMade from alloy steel hardened to 54 – 56rcBalanced to G6.3 at 12,000 rpmsConcentricity is less than .005 micron upto 100 Length and 0.012 upto 200 LengthAll critical tool holder surfaces precision groundCoolant through capabilityGage length is 70mm,100MM,150MM,200MMRear thread for pull stud is M16 X 2.0 All holders have capability to become through coolant by simply removing screw in the center by allen key

Mars-Tech BT40 locking device Tool Bo... ₹ 2,227.00

BT40 Locking device with Vertical and Horizontal mode to tighten Nut and Pull stud made of Steel and long life. cone for taper is made of aluminium . 3.5 kgs of 1 pc.

Mars-Tech MARS-TECH ER32 UM NUT pack ... from ₹ 253.00

Holds all ER32 collets from 1 mm to 20 mmMade from alloy steel hardened to 54 – 56rcPrecision ground ID thread and taperHas an id thread of – M40*1.5POutside diameter is 50 MMSUITABLE SPANNER IS ER32UM AND ER32 C TYPE key to tighteninginternal cam removes collet when unscrewedMARSTECH CODE IS ER32UM TYPE NUT

Mars-Tech ER40 Spanner UM TYPE And C ... from ₹ 289.00

ER40 UM AND C TYPE Spanner Wrench is made from high quality alloy steel ,Thick material allows high torque without bending,4 point contact ensures no distortion of collet nut while tightening,ER40 Wrench works on all of our UM Type and UM type collet chucks that take ER40 collets

Mars-Tech Collet Chuck ER32UM Choose ... from ₹ 1,264.00

Cylindrical Shank / Straight Shank Collet chuck also called Baby collet chuck because of small size and same chuck which comes in BT40 or big tapers , its very useful to increase length of a chuck and also used in turning machine where you have turret sleeve size smaller but straight, its also useful to OEM of machines like Multi Spindle machine and it comes in various sizes to fit in , from Smallest 8 mm to 40 mm are commonly available. This is made from high quality steel and hardened upto 50 hrc for long lasting life ER32 COLLET RANGE FROM 1MM TO 20 MM STANDARD , SUITABLE SPANNER ER32 UM REGO FIX TYPE

Straight Shank Collet Chuck ER16 A And M Type

Collet Chuck ER16 A/M Type In straight shank

Mars-Tech Collet Chuck ER16 A/M Type ... from ₹ 1,023.00

Cylindrical Shank / Straight Shank Collet chuck also called Baby collet chuck because of small size and same chuck which comes in BT40 or big tapers , its very useful to increase length of a chuck and also used in turning machine where you have turret sleeve size smaller but straight, its also useful to OEM of machines like Multi Spindle machine and it comes in various sizes to fit in , from Smallest 8 mm to 40 mm are commonly available. This is made from high quality steel and hardened upto 50 hrc for long lasting life ER16 COLLET RANGE FROM 1MM TO 10 MM STANDARD , SUITABLE SPANNER ER16 A TYPE AND M TYPE

Mars-Tech BT40ER40 collet chuck UM-80... from ₹ 1,505.00

BT40 Tool Holder accepts all ER40 collets ER40 Collets range from 3 mm to 26 mm Thread inside internal stop screwMade from alloy steel hardened to 54 – 56rcBalanced to G6.3 at 12,000 rpmsConcentricity is less than .005 micron upto 100 Length and 0.012 upto 200 LengthAll critical tool holder surfaces precision groundCoolant through capabilityGage length is 70mm,100MM,150MM,200MMRear thread for pull stud is M16 X 2.0 All holders have capability to become through coolant by simply removing screw in the center by allen key

Mars-Tech ER25 Spanner M Type C Type ... from ₹ 217.00

ER25M/A/UM Spanner Wrench is made from high quality alloy steel ,Thick material allows high torque without bending,4 point contact ensures no distortion of collet nut while tightening,ER25 Wrench works on all of our M Type and UM type collet chucks that take ER25 collets

Mars-Tech APU13 Spanner For Keyless D... ₹ 300.00

APU 13 Spanner for Keyless Drill Chuck. Suitable to Only 2 Sizes 1-13 MM And 3-16MM

ER16 Spanner M Type A Type UM Type pack of 1

Mars-Tech ER16 Spanner M Type A Type ... from ₹ 181.00

ER16M/A/UM Wrench is made from high quality alloy steel ,Thick material allows high torque without bending,5 point contact ensures no distortion of collet nut while tightening,ER16 Wrench works on all of our M Type and A type collet chucks that take ER16 collets

Mars-Tech BT40Morse taper holder MT1 ... from ₹ 1,505.00

BT40 Morse Taper holder are used to hold Tang type shanks BT40 morse taper Is mainly used to hold Tang Type Drills and Arbours Better shank taper - accurate, rigid toolholder-to-spindle mount Less tool wear and replacement - less scrap Fully ground flange and V-groove, easy on the tool changers for less spindle and changer maintenance Made from alloy steel hardened to 54 – 56rcBalanced to G6.3 at 12,000 rpmsConcentricity is less than .005 micron upto 100 Length and 0.012 upto 200 LengthAll critical tool holder surfaces precision groundRear thread for pull stud is M16 X 2.0 This is general standard to choose morse taper size for drills (it may change with different din standard or special sizes) MT 1 IS USED FOR SMALL DRILL UPTO 14MM MT 2 IS USED FOR 14.25 MM TO 23 MMMT 3 IS USED FOR 23.5 TO 31.5 MMMT4 IS USED FOR 32TO 49.5MM3

Mars-Tech Collet chuck ER8 M type in ... from ₹ 1,143.00

Cylindrical Shank / Straight Shank Collet chuck also called Baby collet chuck because of small size and same chuck which comes in BT40 or big tapers , its very useful to increase length of a chuck and also used in turning machine where you have turret sleeve size smaller but straight, its also useful to OEM of machines like Multi Spindle machine and it comes in various sizes to fit in , from Smallest 8 mm to 40 mm are commonly available. This is made from high quality steel and hardened upto 50 hrc for long lasting life ER8 COLLET RANGE FROM 1MM TO 5 MM STANDARD

Mars-Tech ER25 Nut UM And M Type pack of 1

Mars-Tech Mars-Tech ER25 Nut UM And M... from ₹ 229.00

Both Type Holds all ER25 collets from 1 mm to 16 mmMade from alloy steel hardened to 54 – 56rcPrecision ground ID thread and taperHas an id thread of – M32*1.5POutside diameter is 42 MMSUITABLE SPANNER IS ER25UM AND ER25 C TYPE key to tighteninginternal cam removes collet when unscrewedMARSTECH CODE IS ER25UM TYPE NUT M TYPE Has an id thread of 30mm X 1.0 pitchOutside diameter is 1.377 inches (35mm)Length is .787 inches (20mm)ER25M-Wrench works on this collet nut UM type EXTRA LONG Has an id thread of – M32*1.5POutside diameter is 42 MM Length is .984 inches (25mm)

Mars-Tech ER Nut ER11 A And M Type PACK of 1

Mars-Tech Mars-Tech ER Nut ER11 A And... from ₹ 198.00

Holds all ER11 collets from 1 mm to 7 mmMade from alloy steel hardened to 54 – 56rcPrecision ground ID thread and taperHEX type Has an id thread of – M14X0.75PHEX NUT Outside diameter is 19 MMNormal key to tighteningER11A-Wrench SPANNER works on this collet nut M TYPE Has an id thread of 13mm X .75 pitchM TYPE Outside diameter is .630 inches (16mm) ER11M-Wrench SPANNER works on this collet nutInternal cam removes collet when unscrewedMARSTECH CODE IS ER11A TYPE NUT

ER16 Collet Ultra high precision 0.005 AAA quality

Mars-Tech ER16 Collet Ultra high prec... from ₹ 566.00

The standard ER collet is the most widely used clamping system in the world.Made from Alloy spring steel and fully hardened these ER collets are ideal for many machining applications including boring, milling, reaming, tapping and grinding. Unless specified differently all of our ER collets feature runout of 0.005 micron or less. ,ER collet sizes start at ER8 through ER50. ER16 series collets have a capacity of 1mm-12mm. Each ER16 collet has a range of (1 mm). The size indicated on the collet is the largest size it can hold and can be collapsed smaller within its collapse range of (0.9mm). For example, ER16-3mm can grab a round shank from 3mm diameter to 2.1mm diameter.

Mars-Tech BT40ER20A-collet chuck 70L,... from ₹ 1,505.00

BT40 Tool Holder accepts all ER20 collets ER20 Collets range from 1 mm to 14 mm Thread inside internal stop screwMade from alloy steel hardened to 54 – 56rcBalanced to G6.3 at 12,000 rpmsConcentricity is less than .005 micron upto 100 Length and 0.012 upto 200 LengthAll critical tool holder surfaces precision groundCoolant through capabilityGage length is 70mm,100MM,150MM,200MMRear thread for pull stud is M16 X 2.0 All holders have capability to become through coolant by simply removing screw in the center by allen key

ER32 Collet Ultra high precision 0.005 AAA quality

Mars-Tech ER32 Collet Ultra high prec... from ₹ 631.00

The standard ER collet is the most widely used clamping system in the world.Made from Alloy spring steel and fully hardened these ER collets are ideal for many machining applications including boring, milling, reaming, tapping and grinding. Unless specified differently all of our ER collets feature runout of 0.010 micron or less. ,ER collet sizes start at ER8 through ER50. ER32 series collets have a capacity of 1mm-20mm. Each ER32 collet has a range of (1 mm). The size indicated on the collet is the largest size it can hold and can be collapsed smaller within its collapse range of (0.9mm). For example, ER32-6mm can grab a round shank from 6mm diameter to 5.1mm diameter.

MARS-TECH ER NUT ER20 A/M/UM TYPE pack of 1

Mars-Tech MARS-TECH ER NUT ER20 A/M/U... from ₹ 210.00

Both types hold all ER20 collets from 1 mm to 14 mmMade from alloy steel hardened to 54 – 56rcPrecision ground ID thread and taperER20A Has an id thread of – M25*1.5PER20A Outside diameter is 34 MMNormal key to tighteninginternal cam removes collet when unscrewedMARSTECH CODE IS ER20A HEX TYPE NUT ER20M Has an id thread of 24mm X 1.0 pitchER20M Outside diameter is 1.102 inches (28mm)Outside has castle notches for tighteningER20M-Wrench works on this collet nutMARSTECH CODE IS ER20M TYPE NUT

Straight Shank Collet Chuck ER20 A and M Type

Collet Chuck ER20 A/M Type in Straight Shank

Mars-Tech Collet Chuck ER20 A/M Type ... from ₹ 1,143.00

Cylindrical Shank / Straight Shank Collet chuck also called Baby collet chuck because of small size and same chuck which comes in BT40 or big tapers , its very useful to increase length of a chuck and also used in turning machine where you have turret sleeve size smaller but straight, its also useful to OEM of machines like Multi Spindle machine and it comes in various sizes to fit in , from Smallest 8 mm to 40 mm are commonly available. This is made from high quality steel and hardened upto 50 hrc for long lasting life ER20 Collet Range From 1mm to 14 Mm Standard , Suitable Spanner ER20 A Type and M Type

Mars-Tech BT40fmb 27 mm Face milling ... from ₹ 1,505.00

BT40 facemill holder also called facemill arbour and facemill adaptor BT40 FMA27 Is mainly used to hold Modular Indexable Cutter with Internal hole of 16 mm any cutter can come with a 27 mm Internal thread but normally 80 mm AND 100 mm Cutters are common in this range. Made from alloy steel hardened to 54 – 56rcBalanced to G6.3 at 12,000 rpmsConcentricity is less than .005 micron upto 100 Length and 0.012 upto 200 LengthAll critical tool holder surfaces precision groundGage length is 50MM,100MM,150MM,200MM,250MM,300MMRear thread for pull stud is M16 X 2.0
