Thumbnail for BT40 FMB FMC FMA Face Milling Holder

BT40fmb 27 mm Face milling holder arbour

Brand - Mars-Tech

₹ 1,505.00

SKU: JBRS0425

Size

FMB27-60L FMB27-100L FMB27-150L FMB27-200L FMB27-250L FMB27-300L

0 LEFT IN STOCK

Get Rs.50 Off on Prepaid Orders above Rs.500 via Razorpay Gateway. (Discount will be applied During Checkout at Payment Gateway) (No Code Required)

Product description

BT40 facemill holder also called facemill arbour and facemill adaptor

BT40 FMA27 Is mainly used to hold Modular Indexable Cutter with Internal hole of 16 mm any cutter can come with a 27 mm Internal thread but normally 80 mm AND 100 mm Cutters are common in this range.

Made from alloy steel hardened to 54 – 56rc
Balanced to G6.3 at 12,000 rpms
Concentricity is less than .005 micron upto 100 Length and 0.012 upto 200 Length
All critical tool holder surfaces precision ground
Gage length is 50MM,100MM,150MM,200MM,250MM,300MM
Rear thread for pull stud is M16 X 2.0

Products are usually delivered in 3-7 days depending upon your location.

0 have this item in their cart.

Add to cart
