Machine Tools & Accessories

Mars-Tech Z Setter high precisin gold... ₹ 7,950.00

Z SETTER 50 MM MAGNETIC Have the central measuing part of the zero setter presetter against a plain surface and aligned if with the outer reference surface. Turn the dial gauge for zero setting. have the cutter touched against the Z zero setter. Once the indicator positio at zero the distance between the tool tip to workpiece is 50mm, +-0.005 mm

Mars-Tech BT50 Pull Stud In Various D... from ₹ 361.00

BT50 Pull stud used in CNC machines for BT40 holders ISO standard name is MAS403 Pull studs are an important link between machine and tool. The requirements concerning accuracy, rigidity and reliability are very high. Pull studs of minor quality not only decrease the performance of the machine, they are even a safety risk. A breaking pull stud might cause severe damage on machine and workpiece and even injuries on persons. made of special steel for higher rigidity proper heat treated ,

Mars-Tech BT40fmb 32mm Face milling ... from ₹ 1,505.00

BT40 facemill holder also called facemill arbour and facemill adaptor BT40 FMA32 Is mainly used to hold Modular Indexable Cutter with Internal hole of 16 mm any cutter can come with a 32 mm Internal thread but normally 100 mm AND 125 mm Cutters are common in this range. Made from alloy steel hardened to 54 – 56rcBalanced to G6.3 at 12,000 rpmsConcentricity is less than .005 micron upto 100 Length and 0.012 upto 200 LengthAll critical tool holder surfaces precision groundGage length is 50MM,100MM,150MMRear thread for pull stud is M16 X 2.0

SDJ Boring bars small sizes pack of 1 carbide shank

Mars-Tech SDJ Boring bars small sizes... from ₹ 12,739.00

SDJ Boring bars are solution for small boring adjustable settings Least Count is 10 Micron Diametrically. these can clamp to any standard collet chuck used for precision boring bars finishing purpose please choose size from variation and kindly use as per instruction

Mars-Tech BT40 fma16 mm face milling ... from ₹ 1,505.00

BT40 fma16 mm face milling holder arbourBT40 face mill holder also called face mill arbour and face mill adaptor BT40 FMA16 Is mainly used to hold Modular Indexable Cutter with an Internal hole of 16 mm any cutter can come with a 16 mm Internal thread but normally 40 mm Cutters are common in this range. Made from alloy steel hardened to 54 – 56rcBalanced to G6.3 at 12,000 rpmsConcentricity is less than .005 micron upto 100 Length and 0.012 upto 200 LengthAll critical tool holder surfaces precision groundGage length is 70mm,100MM,150MM,200MM,250MM,300MMThe rear thread for the pull stud is M16 X 2.0

Hydrogrip Collet Reduction sleeve pack of 1

Mars-Tech Hydrogrip Collet Reduction ... from ₹ 2,699.00

reduction sleeve for hydrogrip holder

Mars-Tech BT40 ER11A Collet chuck-70L... from ₹ 1,505.00

BT40 ER11A Collet chuck-70L,100L,150LBT40 Tool Holder accepts all ER11 colletsThe thread inside internal stop screwMade from alloy steel hardened to 54 – 56rcBalanced to G6.3 at 12,000 rpmsConcentricity is less than .005 micronsAll critical tool holder surfaces precision groundCoolant through capabilityThe gage length is 70mm The rear thread for the pull stud is M16 X 2.0 All holders have the capability to become through coolant by simply removing the screw in the center with allen key

Mars-Tech BT30 Side Lock Adaptor , SL... ₹ 1,505.00

BT30 Side Lock Adaptor, SLA 10,12,16,20,25,32 mm For Cylindrical ShankBT30 SLA holder also called SIDE LOCK HOLDER BT30 SIDE LOCK Is mainly used to hold a Cylindrical/Straight Shank of anything like an Indexable Cutter , Baby chuck, or Carbide Drill whatever a straight shank can hold for better rigidity and strength range from 16 mm to 32 mm as the small diameter of the shank can be held in a standard collet chuck. Made from alloy steel hardened to 54 – 56rcBalanced to G6.3 at 12,000 rpmsConcentricity is less than .005 micron upto 100 Length and 0.012 upto 200 LengthAll critical tool holder surfaces precision groundGage length is 50MM,63MM,80MM,90MMThe rear thread for the pull stud is M12 X 1.75

ER40 Collet Ultra high precision 0.005 AAA quality

Mars-Tech ER40 Collet Ultra high prec... ₹ 802.00

The standard ER collet is the most widely used clamping system in the world.Made from Alloy spring steel and fully hardened these ER collets are ideal for many machining applications including boring, milling, reaming, tapping and grinding. Unless specified differently all of our ER collets feature runout of 0.010 micron or less. ,ER collet sizes start at ER8 through ER50. ER40 series collets have a capacity of 3mm-26mm. Each ER32 collet has a range of (1 mm). The size indicated on the collet is the largest size it can hold and can be collapsed smaller within its collapse range of (0.9mm). For example, ER40-6mm can grab a round shank from 6mm diameter to 5.1mm diameter.

ER8 Ccollet DIN6499B AA 0.005 Ultra high precision Quality Collet.

Mars-Tech ER8 Ccollet DIN6499B AA 0.... ₹ 590.00

The standard ER collet is the most widely used clamping system in the world.Made from Alloy spring steel and fully hardened these ER collets are ideal for many machining applications including boring, milling, reaming, tapping and grinding. Unless specified differently all of our ER collets feature runout of 0.005 micron or less. ,ER collet sizes start at ER8 through ER50. ER8 series collets have a capacity of 1mm-5mm. Each ER8 collet has a range of (0.5mm). The size indicated on the collet is the largest size it can hold and can be collapsed smaller within its collapse range of (0.5mm). For example, ER8-3mm can grab a round shank from 3mm diameter to 2.5mm diameter.

ER25 Collet set 1 mm to16 mm High Quality Precision Collet. Set of 16 nos.

Mars-Tech ER25 Collet set 1 mm to16 m... ₹ 4,634.00

THIS SET HAS 16 COLLETS 1 MM TO 16 MM EACH 1 NOS. The standard ER collet is the most widely used clamping system in the world.Made from Alloy spring steel and fully hardened these ER collets are ideal for many machining applications including boring, milling, reaming, tapping and grinding. Unless specified differently all of our ER collets feature runout of 0.010 micron or less. ,ER collet sizes start at ER8 through ER50. ER32 series collets have a capacity of 1mm-20mm. Each ER32 collet has a range of (1 mm). The size indicated on the collet is the largest size it can hold and can be collapsed smaller within its collapse range of (0.9mm). For example, ER32-6mm can grab a round shank from 6mm diameter to 5.1mm diameter.

ER 32 COLLET SET 1 MM TO 20 MM High Quality Precision Collet. SET OF 20 nos.

Mars-Tech ER 32 COLLET SET 1 MM TO 20... ₹ 7,015.00

THIS SET HAS 20 COLLETS 1 MM TO 20 MM EACH 1 NOS. PACKED IN PLASTIC BOX The standard ER collet is the most widely used clamping system in the world.Made from Alloy spring steel and fully hardened these ER collets are ideal for many machining applications including boring, milling, reaming, tapping and grinding. Unless specified differently all of our ER collets feature runout of 0.010 micron or less. ,ER collet sizes start at ER8 through ER50. ER32 series collets have a capacity of 1mm-20mm. Each ER32 collet has a range of (1 mm). The size indicated on the collet is the largest size it can hold and can be collapsed smaller within its collapse range of (0.9mm). For example, ER32-6mm can grab a round shank from 6mm diameter to 5.1mm diameter.

Sold out

Mars-Tech BT40 APU1-16 Drill Chuck he... ₹ 4,666.00

BT40 APU Drill Chuck heavy duty with yellow jaws 1-16 MM pack of 1BT40 Integrated Keyless Drill Chuck with High Quality and yellow titanium coated jaws for Longer Life, useful for CNC machine BT40 spindle only

Mars-Tech SK40 fma22 FMB FMC FMA Face... from ₹ 1,685.00

SK40 facemill holder also called facemill arbour and facemill adaptor SK40 FMA22 Is mainly used to hold Modular Indexable Cutter with Internal hole of 16 mm any cutter can come with a 22 mm Internal thread but normally 50 mm AND 63 mm Cutters are common in this range. Made from alloy steel hardened to 54 – 56rcBalanced to G6.3 at 12,000 rpmsConcentricity is less than .005 micron upto 100 Length and 0.012 upto 200 LengthAll critical tool holder surfaces precision groundGage length is 50MM,100MM,150MM,200MM,250MM,300MMRear thread for pull stud is M16 X 2.0

Mars-Tech MARS-TECH ER8 NUT ER8 M/A p... ₹ 247.00

Holds all ER8 colletsMade from alloy steel hardened to 54 – 56rcPrecision ground ID thread and taperER8M Collet Nut has an id thread of 10mm X .75 pitchOutside diameter is 12mmOutside has castle notches for tighteningUse ER8M-Wrench for tighteningInternal cam removes collet when unscrewedBlack oxide finish ER8A Collet Nut has an id thread of 10mm X .75 pitchOutside diameter is 13.5mm Use standard wrench for tightening the nut.

Mars-Tech ABT40 ER32um collet chuck 7... from ₹ 3,128.00

ABT40 ER32um collet chuck 70/100/150LABT40 HOLDER CAN FIT INTO BBT40 CALIBRATED SPINDLE ONLY. ABT40 Holder Taper and Both Faces Are in Contact With Spindle Due to Which Spindle and Holder Act as Single Unit This Allows a Higher "Radial Rigidity" Hence We Get a Good Surface Finish and Dimensional Accuracy While Machining Also Low Vibration at Higher Speed Which Increases the Tool Life Collet Chuck Holder Is Balanced to G6.3-12000 Rpm

Sold out

ER16 Collet set 1 mm to 10 mm High Quality Precision Collet. Set of 10 nos.

Mars-Tech ER16 Collet set 1 mm to 10 ... ₹ 2,660.00

THIS SET HAS 10 COLLETS 1 MM TO 10 MM EACH 1 NOS. The standard ER collet is the most widely used clamping system in the world.Made from Alloy spring steel and fully hardened these ER collets are ideal for many machining applications including boring, milling, reaming, tapping and grinding. Unless specified differently all of our ER collets feature runout of 0.010 micron or less. ,ER collet sizes start at ER8 through ER50. ER32 series collets have a capacity of 1mm-20mm. Each ER32 collet has a range of (1 mm). The size indicated on the collet is the largest size it can hold and can be collapsed smaller within its collapse range of (0.9mm). For example, ER32-6mm can grab a round shank from 6mm diameter to 5.1mm diameter.

Mars-Tech 1-13mm drill chuck Shank 32... ₹ 2,648.00

1-13mm drill chuck Shank 32 mm Heavy Duty keyless drill chuck pack of 1CYLINDRICAL Integrated Keyless Drill Chuck with High Quality and heavy duty Jaws for Longer Life, High Accuracy

Mars-Tech 1-13 mm drill chuck ISO 40/... ₹ 4,038.00

1-13 mm drill chuck ISO 40/NT40/DIN2080 shank pack of 1NT40 ISO40 Integrated Keyless Drill Chuck with High Quality and Titanium Coated Jaws for Longer Life, High Accuracy

MAZAK BT40 Pull Stud With Hole And Without Hole

Mars-Tech MAZAK BT40 Pull Stud With H... ₹ 181.00

Mazak BT40 SK40 Pull stud used in CNC machines for BT40 holders ISO standard name is MAS403 Pull studs are an important link between machine and tool. The requirements concerning accuracy, rigidity and reliability are very high. Pull studs of minor quality not only decrease the performance of the machine, they are even a safety risk. A breaking pull stud might cause severe damage on machine and workpiece and even injuries on persons. made of special steel for higher rigidity proper heat treated ,
